Fusion 360 Drawings


What You’ll Learn in This Fusion 360 Drawings Course

Fusion 360 streamlines creating drawings from your 3D designs. Whether you’re detailing a part using dimensions and annotations or looking to create a parts list with balloons on an assembly – you can use Fusion 360 to accurately convey your design.

Leveraging different drawing views (such as section views and exploded views) enables you to easily detail hard-to-see areas. Additionally, creating your drawings in Fusion 360 maintains associativity back to the 3D part or assembly design. If you change the geometry of the 3D design, it will update directly in the drawing. This empowers you to keep all details captured in your drawings, and you can confidently hand them off to other stakeholders or manufacturers.

Key course topics:

  • Get to know the Drawings workspace and frequently used commands
  • Creating an initial drawing with standard view types
  • Adding additional drawing views – projected, detail, section, and exploded views
  • Adding annotations – center marks, centerlines, dimensions, symbols, balloons and parts list, and written notes
  • Tactics for updating the design – model associativity and managing the title block

Dive Into Fusion 360 Drawings

  • 15 video lessons
  • 1 hr 5 min runtime
  • Two guided exercises
  • Two practice exercises
  • Technical certificate available
